ZAD-8565 FULLY AUTOMATIC PULP MOLDING HIGH-END INDUSTRIAL PACKAGINGFORMING MACHINE
The ZAD-8565 is a full-automatic high-end industrial packaging equipment with forming and hot-pressing function. It realizes molding via precision pulp feeding, which not only reduces basis weight deviation but also simultaneously addresses the issues of pulp deterioration and contamination circulation.
With a reasonable template size, the equipment is suitable for maximizing the layout of various industrial pulp molded products, featuring high efficiency and high productivity. The entire equipment covers a small area, and its transfer template can be optionally equipped with a hot-pressing function. It boasts a stable structure, modular design, and few vulnerable parts, thus achieving the goals of easy operation and debugging, easy maintenance, and low failure rate.
Advantages of Products
Higher output , less consumption, high-end solution, perfect product quality
Application
Mainly used to Produce Phone tray, tablet tray,earphone tray,watch tray, mouse tray
MACHINE SPECIFICATIONS
ZAD8565 Cosmetic & skincare pulp package machine | ||
1 | Outer dimension (L*W*H) | 3479mm*1514mm*3803mm |
2 | Platen size | 850mm*650mm |
3 | Forming method | reciprocating |
4 | Pulp feeding style | accurate quantitative pulp feeding (external overflow style) |
5 | Equipment weight | 5.5T |
6 | Product transfer method | transfer in-mold |
7 | Forming pressure | 3T |
8 | Hot pressing pressure | 20T |
9 | Machine drive mode | servo + lead screw & hydraulic system |
10 | Transmission power |
|
11 | Drying method | dry in-mold |
12 | Capacity |
|
13 | Cycle time |
|
14 | Max. product height | 100mm |
Production Flowchart
High-End Industrial Package Machine
Solution for complex structure, 0 angle demolding, make sure finish product with perfect smoothness and strength
