Liquid pulp bottle tray machine ZAM6043

We are excited to introduce the ZAM6043 industrial packaging machine, a versatile and efficient solution for producing linings and outer packaging for a wide range of fine industrial products. This cutting-edge machine is perfect for packaging items such as wine trays, various digital products, high-end cosmetics, and handicrafts, making it an ideal choice for businesses looking to elevate their packaging process.

The ZAM6043 boasts a range of impressive features that set it apart from traditional packaging machines. Its small template and low mold opening cost make it an economical choice for businesses looking to streamline their production process. This machine is particularly well-suited for small batch production, offering flexibility and cost-effective solutions for businesses of all sizes. Whether you are a small-scale producer or a larger corporation, the ZAM6043 is an excellent investment for your packaging needs.

One of the key advantages of the ZAM6043 is its low energy consumption. As environmental sustainability becomes an increasingly important consideration for businesses, this machine offers a responsible and eco-friendly solution for industrial packaging. By minimizing energy usage, the ZAM6043 helps to reduce operational costs while also demonstrating a commitment to environmental stewardship.

In addition to its economic and environmental benefits, the ZAM6043 can also be upgraded to replace manual machines, further enhancing productivity and efficiency. This adaptable feature makes it an excellent long-term investment for businesses looking to optimize their packaging process and stay ahead of industry trends. With the ability to automate packaging processes, the ZAM6043 offers a competitive edge in a rapidly evolving market.

Advantages of Hanson Technology

Higher output , less consumption, high-end solution, perfect product quality

产能上升更新后的
3 0 %+
Capacity per sqm Up by
热能耗下降更新后的
1 0 %
Heating Consumption Less by
清洗周期更新后的
1500 0 +
Mold Deep Cleaning Cycle
90直径产能更新后的
20000 0 +
Daily Output of Ф90mm lid
Commonly Used Raw Material
Primary Pulp Board from the following plants
The commercial primary pulp board for producing premium industrial pulp package is usually the chemical pulp or chlorine-free ECF pulp ,can be purchased from paper making manufacture.A combination of sugarcane ,bamboo and coniferous wood fiber pulp are the raw material applied more for the excellent performace of the pulp tray in replacing plastic tray.

Application

Paper Lid/Compostable Paper Lid/Anti-leak coffee lid/biodegradable lid/pulp lid/hot drink lid/coffee lid

Production Flowchart

ONE-STOP SOLUTION ,TURNKEY PROJECT

MACHINE SPECIFICATIONS



ZAM6043 iquid pulp bottle tray machine

1

Outer dimension (L*W*H)

2600mm*1250mm*3000mm

2

Platen size

610mm*425mm

3

Forming method

reciprocating

4

Pulp feeding style

accurate quantitative pulp feeding (external overflow style)

5

Equipment weight

3.5T

6

Product transfer method

transfer in-mold

7

Forming pressure

2T

8

Hot pressing pressure

10T

9

Machine drive mode

servo +  screw + electric cylinder

10

Transmission power

11kw

11

Drying method

dry in-mold

12

Capacity

80-200KG/22H

13

Cycle time

38-120 seconds/drop (depends on the product)

14

Max. product height

100mm

播放视频

High-End Industrial Package Machine

Solution for complex structure, 0 angle demolding, make sure finish product with perfect smoothness and strength

Why Choose Us

Intelligent pulping system

Intelligent pulping system
Online overflow
DCS control
PID frequency conversion control technology

Overall plant design& layout

Overall project management
Turn key project
International service
Whole life support

Pulp molding thermoforming machine

Tableware machine
Cutlery machine
High industrial package machine
Leak-proof lid machine

Mold design and manufacturing

Professional mold designing
High-precision processing ability
Three-coordinate detecting mold solution

Post-process automation

Intelligent transfer solution
Automatic visual inspection
Automatic counting
Auto packaging

Technique output and other services

Hanson College
Professioanl technical team
International installation&commissioning
Online support
